Technical Specifications
Transfer rate : 12Gb/s SAS per lane 6Gb/s SATA per lane PCI Express 3.0 x8 lane width
Form factor : Standard PCIe plug-in controller
Ports : External: 8 SAS lanes across 2 x4 Mini-SAS HD ports
Cache : No cache
RAID levels : 0, 1, 5, 10
Servers supported : HPE ProLiant DL360 Gen10 HPE ProLiant DL380 Gen10 HPE ProLiant DL560 Gen10 HPE ProLiant DL580 Gen10 HPE ProLiant ML110 Gen10 HPE ProLiant ML350 Gen10 HPE ProLiant XL170r Gen10 HPE ProLiant XL190r Gen10 HPE ProLiant XL230K Gen10
Additional features : HPE Smart Array SR Secure Encryption (optional license)
Supported disk enclosure : HPE D3610 Disk Enclosure HPE D3710 Disk Enclosure HPE D6020 Disk Enclosure HPE MSA 1040 SAN Storage HPE MSA 1050 SAN Storage HPE MSA 2040 SAN Storage HPE MSA 2050 SAN Storage
Warranty : The warranty for this device is 3-years parts only.
