| Chipset |
Intel® C236 |
| Mainboard type |
D 3521 |
| Product Type |
Mono Socket Economy Server |
| Processor |
Intel® Xeon® processor E3-1200 v6 product family, Intel® Celeron®processor, Intel® Core™ i3 processor, Intel® Pentium® processor
1 x Intel® Xeon® processor E3-1200 v6 product family, Intel® Celeron®processor, Intel® Core™ i3 processor, Intel® Pentium® processor |
| Memory |
4 GB - 64 GB, DIMM (DDR4)
4 GB - 32 GB, DIMM (DDR4) |
| Drives (optional) |
DVD supermulti, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0 |
| PCI-Express 3.0 x4 (mech. x16) |
1 x Full height, up to 215 mm length |
| PCI-Express 3.0 x16 |
1 x Full height, up to 240 mm length |
| Slot Notes |
Standard: 2x PCIe x1 (notched), both slots are Full height. One slot up to 215mm Length and one slot up to 168mm Length, Basic: n.a. |
| Optional accessible drives |
2 (1x 9.5mm for DVD/DVD-RW, 1x 5.25-inch half height) |
| Storage drive bays |
4 x 3.5-inch cold-plug SATA
2 x 3.5-inch easy change SATA
SATA only |
| Storage drive type |
HDD SATA, 6 Gb/s, 10 TB, 7,200 rpm, 512e, non hot plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 12 TB, 7,200 rpm, 512e, non hot plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 8 TB, 7,200 rpm, 512e, non hot plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 1 TB, 7,200 rpm, 512e, non hot plug, 3.5-inch, economic
HDD SATA, 6 Gb/s, 1 TB, 7,200 rpm, 512n, non hot plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 2 TB, 7,200 rpm, 512n, non hot plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 4 TB, 7,200 rpm, 512n, non hot plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 6 TB, 7,200 rpm, 512e, non hot plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 500 GB, 7,200 rpm, 512e, non hot plug, 3.5-inch, economic |
| I/O controller onboard |
4 port SATA with RAID 0/1/10 for HDDs
Intel® i219 onboard
10/100/1000 Mbit/s Ethernet |
| Trusted Platform Module (TPM) |
Infineon / TPM 1.2 or TPM 2.0 module; TCG compliant (option) |
| Power supply configuration |
1 x standard power supply |
| Active power (max. configuration) |
139 W |
| Weight |
up to 12 kg |
| Floor-stand (W x D x H) |
180 x 313 x 374 mm |
| Server Management |
Server Management |
| Standard |
ServerView Suite - Deploy
Installation Manager
Scripting Toolkit, ServerView Suite - Control
Operations Manager
Agents and CIM Providers / Agentless Service
System Monitor
RAID Manager
Capacity Management
Storage Support, ServerView Suite - Maintain
Update Management (BIOS, Firmware, Windows Drives and SV Agents)
Performance Measurement
Asset Management
Online Diagnostics, ServerView Suite - Integrate
Integration packs for Microsoft System Center, VMware vCenter, VMware vRealize, Nagios, and HP SIM (restricted functionality) |
| Option |
- |
| Special features |
The ideal server for SMEs and their essential workloads. Cost effective, right sized price/performance ratio, reliable, silent, compact and easy to service. Ideal for essential SME tasks such as file, print, web, office applications or even industry-specific applications. |
| Warranty period |
1 year |
| Warranty type |
Onsite Service |
| Service Weblink |
5 years after end of product life
http://www.fujitsu.com/fts/products/product-support-services/ |
| Service Weblink |
5 years after end of product life
http://www.fujitsu.com/fts/products/product-support-services/ |
